Copyright © 2006-2019 MultiMedia Soft SPECTR_ENH_WAVE_SETTINGS structure

The SPECTR_ENH_WAVE_SETTINGS data structure (defined as SPECTR_ENH_WAVE_SETTINGS_DLL when used for COM interoperability) describes the graphical settings applied to the spectrum wave displayed on the spectrum analyzer. The current settings can be obtained through the SpectrumEnh.SettingsWaveGet method and modified through the SpectrumEnh.SettingsWaveSet method.



For further details about using the Enhanced Spectrum Analyzer refer to the SpectrumEnh section.

For details about using the Enhanced Spectrum Analyzer refer to the How to use the Enhanced Spectrum Analyzer tutorial.



C# definition



public struct SPECTR_ENH_WAVE_SETTINGS

{

 public Int16 nAreaTransparency;

 public bool bClearSpectralViewOnEnd;

 public Color colorLineTopLeftChan;

 public Color colorLineTopRightChan;

 public Color colorLineCoveredLeftChan;

 public Color colorLineCoveredRightChan;

 public Color colorAreaLeftChan;

 public Color colorAreaRightChan;

 public Color colorAreaCoveredLeftChan;

 public Color colorAreaCoveredRightChan;

 public Color colorVertLineSpectralView;

}



Definition for COM Interoperability



public struct SPECTR_ENH_WAVE_SETTINGS_DLL

{

 public Int16 nAreaTransparency;

 public Int16 bClearSpectralViewOnEnd;

 public Int32 colorLineTopLeftChan;

 public Int32 colorLineTopRightChan;

 public Int32 colorLineCoveredLeftChan;

 public Int32 colorLineCoveredRightChan;

 public Int32 colorAreaLeftChan;

 public Int32 colorAreaRightChan;

 public Int32 colorAreaCoveredLeftChan;

 public Int32 colorAreaCoveredRightChan;

 public Int32 colorVertLineSpectralView;

}





Below you can see an image of the enhanced spectrum analyzer evidencing some of the configurable elements:





In the image above the left channel, which is represented on top respect to the right channel, is rendered through the cyan line and through the blue area while the left channel, partially covered by the left channel, is rendered through the red line and through the darker red area; the portion of right channel area covered by the left channel's area is rendered in violet.

As you can see, frequency and dB grids are still partially visible also when covered by channels areas: this is obtained by rending areas in transparency through the setting of the nAreaTransparency field: in this case the value was set to 25.
