Classes > MIDIMan class > Methods > MIDI.KeyboardCreate method

Remarks

Creates a new virtual piano keyboard on the given parent window.

Notes played on the virtual piano, through the left button of the mouse, will be directly sent to the MIDI stream in playback on the given player.

Keys pressure/release can be simulated through the MIDI.KeyboardNote method, for example for displaying a note played through an external physical MIDI keyboard attached to one of the MIDI input channels.

The container application is notified each time a key on the virtual keyboard is pressed or released through the CallbackForMidiKeyboardEvents delegate.

For further details about the use of MIDI protocol see the MIDIMan class section and the How to deal with MIDI protocol tutorial.

Syntax

[Visual Basic]

Public Function KeyboardCreate (

nPlayerIndex as Int16,

hWndParent as IntPtr,

nLeft as Int32,

nTop as Int32,

nWidth as Int32,

nHeight as Int32,

nLowNote as Int16,

nHighNote as Int16,

bSendEventNotif as Boolean,

nOrientation as enumMidiKeyboardOrientations

) as IntPtr

[C#]

public IntPtr KeyboardCreate (

Int16 nPlayerIndex,

IntPtr hWndParent,

Int32 nLeft,

Int32 nTop,

Int32 nWidth,

Int32 nHeight,

Int16 nLowNote,

Int16 nHighNote,

bool bSendEventNotif,

enumMidiKeyboardOrientations nOrientation

);

[C++]

public: IntPtr KeyboardCreate (

Int16 nPlayerIndex,

IntPtr hWndParent,

Int32 nLeft,

Int32 nTop,

Int32 nWidth,

Int32 nHeight,

Int16 nLowNote,

Int16 nHighNote,

bool bSendEventNotif,

enumMidiKeyboardOrientations nOrientation

);

Parameter

Description

nPlayerIndex

Number representing the zero-based index of the involved player

hWndParent

Handle of the parent window, usually the container form.

nLeft

Left position of the keyboard window, expressed in client coordinates (pixels) of hWndParent

nTop

Top position of the keyboard window, expressed in client coordinates (pixels) of hWndParent

nWidth

Width of the keyboard window, expressed in pixels

nHeight

Height of the keyboard window, expressed in pixels

nLowNote

Lower note displayed on the virtual piano keyboard. Can be a value between 0 and 127 but must always be a natural note (white key).

nHighNote

Higher note displayed on the virtual piano keyboard. Can be a value between 2 and 127 but must always be a natural note (white key).

bSendEventNotif

Boolean flag that specifies if the container application must be notified about the notes played on the keyboard through the CallbackForMidiStreamEvents delegate.

Supported values are the following:

Value	Meaning
false	The CallbackForMidiStreamEvents delegate is not invoked for notes played on the piano keyboard.
true	The CallbackForMidiStreamEvents delegate is invoked for notes played on the piano keyboard.

nOrientation

Orientation of the piano keyboard.

Supported values are the following:

Mnemonic constant	Value	Meaning
MIDI_KEYB_ORIENT_HORIZONTAL	0	The piano keyboard orientation is horizontal as in the picture below
MIDI_KEYB_ORIENT_VERTICAL_LEFT	1	The piano keyboard orientation is left vertical as in the picture below
MIDI_KEYB_ORIENT_VERTICAL_RIGHT	2	The piano keyboard orientation is right vertical as in the picture below

Return value

Value	Meaning

IntPtr.Zero	An error occurred, check the LastError property value in order to get the error code
Other values	Handle (HWND) of the new graphic bar
